Internal Valve Hydraulic Rock Jack Hammer JONYANG JY200 JY210 For Excavator

Name: Internal Valve Hydraulic Rock Jack Hammer JONYANG JY200 JY210 For Excavator
Brand: haofa
Price: 1 USD

Quality Internal Valve Hydraulic Rock Jack Hammer JONYANG JY200 JY210 For Excavator for sale

Brand Name : haofa

Model Number : Hammer Rock Breaker

Certification : CE, ISO9001

Place of Origin : china

MOQ : 1pc

Price : Negotiate

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 10000pcs/month

Delivery Time : 3-5days

Packaging Details : Wooden box

Valve : Internal Valve Type Breaker

Package : Wooden Cases Or Pallets

Carrier : 19-26 Ton Excavator

Chisel Type : Moil, Wedge, Flat, Blunt, Conical Type Chisel Working Pressure: 160-180 Kg/cm2

High Light : hydraulic hammer breaker, excavator jackhammer

Contact Now

Internal Valve Hammer Rock Breaker , JONYANG JY200 JY210 Hydraulic Jack Hammer

Description

1. Supplied ready to use with hydraulic hoses, tool, N2 gas charging kit
2. Easy fitment onto any kinds of excavators
3. Durable body incorporating heavy duty rock claws
4. Perfectly matched tool and piston ensure maximum energy transfer to the material being broken
5. The hydraulic accumulator gives greater acceleration in the power stroke and reduces pressure peaks in the carrier hydraulic system.

Hydraulic Breaker Type

Side type hydraulic breaker has the advantage of convenient maintenance and flexible operation, it's the first choice for mining and quarrying.
Top type hydraulic breaker is applied to special operation that in larger elevation angle at municipal project dismantling.
Silence type hydraulic breaker is fully compliance with international environmental standards,it can adapt to the urban demolition work and tunnel construction.

Application

1. mining—mining, second-time breaking
2. metallurgy—clearing slag, demolition of furnace and foundation
3. road—repairing, breaking, foundation work
4. railway—tunneling, demolition of bridge
5. construction—demolition of bulinding and reinforced concrete
6. ship repairing—clearing clam and rust from the hull
7. others—breaking frozen mud

Internal Valve Hydraulic Rock Jack Hammer JONYANG JY200 JY210 For Excavator

Specification

Model	Weight (Kg)	Length (Mm)	Pressure (kg/cm2)	Flux (L/Min)	Rate (Bpm)	Hose (Inch)	Chisel (Mm)	Suit (Ton)
JSB200	100/120	1100	90-120	15-25	700-1200	1/2	45/53	1.2-3.0
JSB400	298	1347	110-140	25-45	500-900	1/2	68/70	3.0-5.5
JSB600	421	1528	110-160	30-45	500-800	1/2	75	4.0-7.0
JSB800	577	1920	120-170	45-85	400-700	3/4	85	7.0-14
JSB900	973	2260	150-170	80-120	400-700	3/4	100	11-16
JSB1600	1855	2695	160-180	120-160	400-700	1	135	19-26
JSB1900	1989	2810	160-180	130-170	400-600	1	140	19-26
JSB2800	2420	2895	160-180	150-190	350-500	1	150	27-38
JSB3500	2750	3152	160-180	170-220	250-400	1	155	28-40
JSB4500	3160	3310	160-180	200-300	250-350	1.25	165	36-45
JSB5000	4210	3400	160-180	210-290	200-350	1.25	175	40-55
JSB5500	4720	3400	180-220	220-300	200-250	1.25	185	50-60
JSB6000	4910	3420	180-220	230-320	180-200	1.25	190	55-65
JSB6500	6100	3700	190-230	360-450	120-200	1.25	210	65-100
